Axxiom / Schmidt Thompson® II XL™ Metering Valve

SKU: P-GV2153

The Thompson Valve II XL™ showcases Axxiom’s continuous improvement process. Adding XL™ technology to the legendary Thompson valve, this premium valve lasts up to 10 times longer than all previous Thompson valves, due to its unique engineering.

Withstands aggressive medias (like steel grit or aluminum oxide) and high-wear dusty abrasives.
Will support up to a #12 (3/4″) blast nozzle
Upgraded components and internal wipers to keep the critical areas protected
Most universal of the Axxiom XL™ series of valves – supports robotic, high-volume blasting
Sold Individually
Many choices of sizes and tungsten sleeve configurations, as follows:
- 1″ base, std. sleeve. MPN: 2153-006
- 1.25″ base, std. sleeve. MPN: 2153-007
- 1.5″ base, std. sleeve. MPN: 2153-008
- 1.25″ base, slotted sleeve. MPN: 2153-217
- 1.5″ base, slotted sleeve. MPN: 2153-218
- 1.25″ base, multi-port sleeve. MPN: 2153-437
- 1.5″ base, multi-port sleeve. MPN: 2153-438
- (slotted and multi-port sleeves are designed to limit the maximum abrasive flow, saving abrasive when the valve is opened too far.)

Categories: Abrasive Blasting Metering Valves & Parts, All Products, Blasting Tags: abrasive, metering, pot, Sandblasting, thompson, valve, xl

Axxiom / Schmidt Thompson® II XL™ Metering Valve

SKU: P-GV2153

Web price i

$4,411.62
$4,010.56 (excludes GST)

Ship to

Nipple Size
Product Type
Quantity

$4,010.56

	Image				Product Notes	Purchase Price	Qty
GV2153007		1-1/4'' x 1-1/4''	Standard Tungsten Carbide sleeve	-		$4,411.62 $4,010.56 (excludes GST)
GV2153008		1-1/2'' x 1-1/2''	Standard Tungsten Carbide sleeve	-		$4,411.62 $4,010.56 (excludes GST)

Add to Cart

Axxiom / Schmidt Thompson® II XL™ Metering Valve

Sku: P-GV2153

The Schmidt Thompson® Valve II XL™ was specifically designed metering valve to give extended life to the harshest blasting environments available. As an example in the pipe blasting industry, where the operators use Alox or aluminum oxide and are working 24/7, 365 days/year. Typical Valves in that application fail every 3-4 weeks work, the Thompson® Valve II XL™ valve is engineered to perform in that environment, extending life by 6-10x. Some of the unique features of the Thompson® Valve II XL™ which give you longer service life.

The XL Sleeve has an internal wiper to ensure that the dust and abrasive stay in the lower region, and it doesn't migrate into the air chamber or piston, preventing the valve from binding up.
Has a triple seal on the plunger as another precaution to ensure that dust doesn't penetrate the upper chambers of the valve
Engineered to have extra material on the castings in the high wear areas to give extra life
Piston has recess in it that helps keep the spring in alignment all the time and the straighter we keep the spring the faster it can cycle.... a fast cycle will give you longer service life from the metering valve.

Other features include and upgraded clean out plug, with a face seal, straight thread, to enable fast clean outs in the field when you have no special tools. And the signal line is in an easy to reach area to give you access to do maintenance.

Note: The Thompson II XL™ valve can be used interchangeably with any other Thompson valve, without modification. Many parts are interchangeable as well. See the manual for details.

		Purchase Price	Qty
GV215200005	Schmidt Thompson Valve 2 Piston	$220.89 $200.81 (excludes GST)
GV215200010	Schmidt Thompson Valve 2 Urethane Seat	$85.33 $77.57 (excludes GST)
GV215200007	Schmidt Thompson Valve 2 Plunger	$1,134.40 $1,031.27 (excludes GST)
GV215200011	Schmidt Thompson Valve 2, 1-1/2″ Base Nipple	$376.37 $342.15 (excludes GST)
GV214950006	Schmidt Thompson Valve 1 Plunger Seal.	$57.15 $51.95 (excludes GST)
GV215200021	Schmidt Thompson® Valve 2 O-Ring for TC Sleeve	$36.82 $33.47 (excludes GST)
GV214900004	Schmidt Thompson Valve 1 Piston Seal	$33.39 $30.35 (excludes GST)
GV215200025	Schmidt Thompson Valve 2 Vibration Disc	$31.28 $28.44 (excludes GST)
GV215200003	Schmidt Thompson® Valve II Spring	$134.99 $122.72 (excludes GST)
P-AFSIL	Breather Vent	$10.35 - $30.68 $9.41 - $27.89 (excludes GST)	See Options
GV214900008PKG	Schmidt Thompson Valve 1 Half Inch Nut	$28.38 $25.80 (excludes GST)
GV215300099	Schmidt Thompson® Valve II XL™ Rebuild Kit	$3,998.62 $3,635.11 (excludes GST)
GV215300098	Schmidt Thompson® Valve II XL™ Seals Repair Kit	$253.06 $230.05 (excludes GST)
